Documentation
1.1.0

Azure Setup Steps

Step 1: Create an Azure Storage Account

  1. Log in to the Azure Portal: Go to Azure Portal.
  2. Navigate to Storage Accounts: In the left-hand navigation pane, search for Storage Accounts and select it.
  3. Create a New Storage Account:
    • Click on + Create.
    • Subscription: Select the Azure subscription to use.
    • Resource Group: Select an existing resource group or create a new one.
    • Storage Account Name: Enter a globally unique name for your storage account.
    • Region: Choose the region where you want to host your storage account.
    • Performance: Choose between Standard and Premium, depending on your performance needs.
    • Replication: Select the redundancy option (e.g., LRS, GRS) based on your data durability requirements.
    • Click Review + Create, and then Create.
  4. Wait for Deployment: Once the deployment is complete, you’ll be able to access the newly created storage account.


Step 2: Create a Blob Storage Container

  1. Go to Your Storage Account: Once the storage account is created, go to it in the Azure Portal.
  2. Navigate to Blob Service: Under Data Storage, select Containers.
  3. Create a New Container:
    • Click + Container.
    • Name: Enter a name for your container (e.g., fileuploads).
    • Public Access Level: Choose the desired access level (Private or Blob).
    • Click Create.


Step 3: Generate a Shared Access Signature (SAS) Token

  1. Go to Shared Access Signature: In the Security + Networking section of your storage account, select Shared access signature.
  2. Set Permissions: Enable the necessary permissions for the SAS token:
    • Permissions: Enable Read, Write, Delete as required.
    • Allowed Services: Enable Blob.
    • Allowed Resource Types: Enable Object.
  3. Set Expiry and Start Times: Configure the validity period for your SAS token.
    • Start Time: Set the start time.
    • Expiry Time: Set the expiry date/time.
  4. Generate SAS Token: Click on Generate SAS and Connection String, copy the generated SAS token, and store it in a notepad.

The generated SAS token will include several parameters, such as:

  • sv (Service version)
  • ss (Service)
  • srt (Resource type)
  • sp (Permissions)
  • se (Expiry time)
  • st (Start time)
  • spr (Protocol)
  • sig (Signature)


OutSystems Component Setup

Step 1: Install the Component

  1. Download the Component: Access the OutSystems Forge and download the Azure Blob Storage Component.
  2. Install the Component: In OutSystems Service Studio, navigate to the "Forge" tab, search for "Azure Blob Storage Component," and click Install.
  3. Add to Your Application: Include the component in your OutSystems application by adding a reference to it.

Step 2: Configure SAS Token and API Integration

  1. Open Your Application Module: In OutSystems, open the application where you’ll be integrating Azure Blob Storage.
  2. Configure SAS Token, Container Name, and Base URL:
    • SAS Token: Set the SAS token as a setting (ODC). This token will be automatically included in the API call as query parameters such as sv, ss, srt, sp, se, st, spr, and sig.
    • Container Name: Store the container name as a settings (ODC), making it easily configurable without changing the application logic.
    • Base URL: Define the base URL for Azure Blob Storage as a settings (ODC). For example: https://.blob.core.windows.net. Please note that if you are using Azure Gov Cloud, the URL format will be different.
  3. Pass File Parameters:
    • FileName: The file name will be passed as part of the URL in the API request.
    • FileData: The binary file data will be passed as a body parameter in the API request.

Support

For support or issues, please reach out to Cloud And Things or contact the contributor, Smit Shiroya.
